Model Number:
OLT-UV-260Compliance:
CE CertifiedMinimum Order Quantity:
1Voltage:
108V-380V 50HZDimension(L*W*H):
680*1300*1500mmPackaging Details:
Standard export wooden boxDelivery Time:
8-10 dayStandard Features of Accelerated UV Aging Testing Chamber
♦ Fluorescent UV lamps (8) - 40 W
♦ Black Panel Temperature (BPT) at controlled, BPT 30~70℃
♦ Temperature from Ambient to 90℃
♦ Spraying water, automatic water supply
♦ Water reservoir 50 Liter
♦ Can hold 48 pieces of specimens
♦ Programmable color display touch screen controller
♦ Safety protection system
♦ Easy to mount samples on the holders
♦ CE and RoHS compliance
Model
OLT-UV-260
OLT-UV-SI-260
Internal dimensions (mm)
450*1170*500
450*1170*500
Overall dimensions (mm)
680*1300*1500
680*1300*1500
Capacity of test specimens
48 pieces Individual specimen size is 75mm * 150mm
48 pieces Individual specimen size is 75mm *150mm
Controller
Programmable color display touch screen controller
Programmable color display touch screen controller
Temperature range
Ambient~90℃ ±2℃
Ambient~90℃ ±2℃
Humidity range
≥95%R.H ±2%R.H
≥95%R.H ±2%R.H
Black Panel Temperature
BPT 30~80℃
BPT 30~80℃
Irradiation Source
Fluorescent UV lamps (8) - 40 W
Fluorescent UV lamps (8) - 40 W
UV wavelength
290 ~ 400nm
290 ~ 400nm
Irradiance Control
N/A
0.3 ~ 20 W/m2(340 nm / 313 nm)
Water Spray
Spraying water
Spraying water
Distance of Specimen and lamp
50mm
50mm
Nominal power
5000W
5500W
Power Supply
108V-380V 50HZ
108V-380V 50HZ
Accelerated UV Aging Testing Chamber is equipped with fluorescent UV lamp which can simulate the UV spectra of sunlight, exposes materials to alternating cycles of UV light, moisture and temperature at controlled. It simulates dew and rain with condensing humidity and/or water spray.
Pre-Sales Service
Inquiry and consulting support.
Offering quotation and specifications.
Provide test solutions.
Visiting our factory.
Standard and custom
After-Sales Service
3 Years Warranty, Lifelong Follow-up Services.
Training how to install and operate the machine.
Training how to maintain the machine.
Response within 24 hours once got questions from customers.
Send spare parts within 2 days after got notice.
Engineers available to service machines overseas to install and commissioning.
Installation instructions
Operation manual and video available for installation & operation
Package with export standard wooden box, It can be used for sea, air, railway, truck transportation.
