Lead Time:
3-5Model Number:
OLT-BL-G1Compliance:
CE CertifiedMinimum Order Quantity:
1Warranty:
1 yearProduct Description
The device is specially aimed at organic solvents, and the inert gas medium formed by circulating nitrogen is used to replace the usual air medium for spray drying. In addition to recycling products, organic solvents can be recovered. In view of the characteristics of low flash point or micro toxicity of organic solvents, it is flammable and explosive. The closed cycle spray system is specially designed.
Parameter
Main features
Closed loop high temperature spray dryer
OLT - BL-G1
OLT - BL-G3
OLT - BL-G5
NMP evaporation
0.8Kg/h
3Kg/h
5Kg/h
Minimum feed volume
50ml
80ml
100ml
Atomization structure
Atomization system
Electronic control system
Closed cycle atomization system
Maximum inlet temperature (centigrade)
100
The diameter of the drying chamber (mm)
300
800
800
Height of dry tower (mm)
600
1200
1500
Diameter of explosion-proof sheet (mm)
65
65
108
Heater capacity
4kw
8kw
18kw
Draft fan [power (kw), air volume (m /h)]
[1.5,250]
[2.2,300]
[2.2,300]
Compressor [power (kw), air volume (L /min)]
[0.58,108]
[0.58,108]
[0.58,108]
Water chilling unit
50-60Hz (built-in cryogenic cooling cycle pump)
Standard of main electrical accessories (including PLC, analog module, touch screen) (optional)
Control module (standard), delta control module, SIEMENS control module, Germany.
On the other hand
Standard of electrical auxiliary accessories selection (including Contactors) (optional)
CHINT (standard): Deli, Schneider.
Contact with the material (optional)
SUS304 SUS316
Exhaust reutilization, energy saving over 30% (optional)
Assembly (standard) / assembly
Atomizing nozzle (using diamond coating)
(SUS304) (standard) SUS316 (standard) silicon carbide (standard) diamond
Equipment warranty
1 years (standard, above must be charged a certain maintenance cost) for 2 years, 3 years.
Electric power (installed capacity)
10kw
16kw
35kw
Pulse bag filter
Polytetrafluoroethylene film mulching material
2
4
8
Shape size (mm) (L*W *H) Reference resources
1400*1000*1600
1800*1200*1800
2100*1200*1800
Installation weight (Reference)
500 pounds
450kg
1000kg
Power supply
380V/-3: it can be customized according to different national standards.
Remarks
280 NMP evaporation at inlet temperature of 0.
1,It can prevent oxidation, avoid danger and improve quality.
2,Easy to achieve aseptic dust free.
3,It can be used to recover the solvent in the liquid.
4,Improve the preservation of aromatic components.
5,It is capable of drying or cooling granulation of flammable liquid.
6,It can dry very high heat sensitive material.
7,It can achieve low public hazards and no public hazards.
8,It can save the deodorizer.
9,It can be dried at low temperature below 100 degrees C.
Product advantage
1,Non oxidizing ceramics, superhard alloys and high efficiency battery materials.
2,Seasoning, healthy food.
3,Medical products, vitamins, organic drugs.
4,Synthetic resin wax
