Portable Lab High Performance LED Screen Handheld Homogenizer

  • Lead Time:

    3-5

  • Product Orgin:

    China

  • Shipping Port:

    Xiamen

  • Model Number:

    JY92-IIDN

  • Minimum Order Quantity:

    1

  • Screen:

    LCD

  • Power:

    220V/110V/ 50Hz/60HZ
  • Product Details

Product Description

Ultrasonic processor is one of the commonly used equipment for laboratory sample pretreatment. It is widely used in the fields of nano industry, biology, chemical industry, pharmacy, dyes, optics, jewelry, aerospace, hardware, and automobile manufacturing.
Main Application:
1. Traditional Chinese medicine extraction, cell, bacteria, and viral tissue disruption. For example, extraction
of cell contents.
2. Dispersion and homogenization of substance particles and emulsification of products. For example, dispersion
of nanomaterials (silica, carbon dioxide, carbon nanotubes, graphene, etc.).
3. Accelerate dissolution and accelerate chemical reactions. For example for chemical synthesis.

Product Parameter


Model
JY96-IIN
JY88-IIN
JY92-IIN
Power
1.5-150W continous adjustable
10-1000W continous adjustable
20-1200W continous adjustable
Mixing capaciity
0.1-150ml
0.1-750ml
0.1-1000ml
Display mode
Touch screen
Ultrasonic setting time
0.1-99.9S
Total time setting
1-99H59M59S
Frequency range
20-25khz
19.5-20.5khz
19.5-20.5khz
Temp control range
0-100℃
Alarm Functions
Time,temp,overload,no-load
Probe(standard)
Φ6(mm)
Φ6(mm)
Φ20(mm)
Optional probe
Φ2,3,8(mm)
Φ2,3,8,10(mm)
Φ2,3,10,12(mm)
Data storage
20 sets
Power(optional 110V)
220V/110V/50Hz/60Hz
Optional function
cumputer+data printing finction+soundproof cabinet Lighting and serilization
Controlling mode
Single chip microcomputer +TFT touch control
Voice alarm and prompt function
Yes


Model
JY92-IIDN
HX-IIN
JY98-IIDN
Power
10-900W continous adjustable
10-1000W continous adjustable
20-1200W continous adjustable
Mixing capaciity
0.1-600ml
0.1-750ml
0.1-1000ml
Display mode
Touch screen
Ultrasonic setting time
0.1-99.9S
Total time setting
1-99H59M59S
Frequency range
20-25khz
19.5-20.5khz
19.5-20.5khz
Temp control range
0-100℃
Alarm Functions
Time,temp,overload,no-load
Probe(standard)
Φ6(mm)
Φ6(mm)
Φ20(mm)
Optional probe
Φ2,3,10,12,15(mm)
Φ2,3,8,10,12,15(mm)
Φ3,6,10,15,20,25,28(mm)
Data storage
20sets
Power(optional 110V)
220V/110V/50Hz/60Hz
Optional function
cumputer+data printing finction+soundproof cabinet Lighting and serilization
Controlling mode
Single chip microcomputer +TFT touch control
Voice alarm and prompt function
Yes


Titanium Alloy Tips/Probe/Horn size reference value
Probe size
Power range suitable
Capacity range
Power rate
Φ2
Power less   than 1000W
0.2-5ml
1-35%
Φ3
3-10ml
1-45%
Φ6
10-100ml
1-60%
Φ8
20-200ml
1-70%
Φ10
30-300ml
10-90%
Φ12
50-500ml
20-95%
Φ10
Power higher than 1200W
30-300ml
1-70%
Φ15
100-600ml
1-80%
Φ20
100-1000ml
10-90%
Φ22
200-1000ml
20-95%
Φ25
500-1500ml
40-95%

Product Applacations



Packing & Shipping
