Item NO.:
VP90LLead Time:
7daysShipping Port:
XiaMen
|
No |
Item |
Data |
| 1 |
Equipment size |
1105W*1488D*1842Hmm (2158mm with signal lamp height) |
| 2 |
Host specification: |
8 floors |
| 3 |
Electrode plate |
402W*450Dcm |
| 4 |
Electrode distance |
48mm |
| 5 |
Signal indicator |
3 ribbon alarm |
| 6 |
Vacuum pump |
90m3/h bipolar oil pump |
| 7 |
Vacuum measurement |
Japan ulvac vacuum gauge |
|
RF power supply |
RF power frequency |
13.56MHz |
|
RF power |
1000W |
|
|
RF power matcher |
Fully automatic matching, leading air capacitor technology |
|
System Power & Machinery |
Power supply |
AC380V, 50/60Hz |
|
rated power |
5000W |
|
|
System weight |
＜600Kg |
|
|
Equipment size |
1805(W)×1988(D)×1842(H)cm |
|
Equipment prerequisites |
Power supply |
7.5KVA |
|
Compressed air requirements |
Anhydrous and oil-free CDA 60～90psig |
|
|
Exhaust system |
≥2 cubic meters per minute, the central exhaust gas treatment pipeline is enough |
|
|
System ambient temperature requirements |
≤30℃(The best room temperature) |
|
|
Process gas requirements |
15～20psig 99.996% or above purity |
Applications
|
Chip industry |
Activation and cleaning before painting, welding, and bonding greatly improve production efficiency and the stability and reliability of product quality |
|
Circuit board industry |
Plasma cleaning FPC circuit board decontamination, carbide treatment, effectively enhance the bonding force of the circuit board to ensure the quality of circuit welding |
|
Led industry |
Plasma cleaning of led stents improves adhesion, facilitates silver glue tiling and chip bonding, improves wire bonding, reduces bubbles, and improves luminous efficiency |
|
Mobile phone industry |
Mobile phone TP bonding, middle frame, back cover, display surface activation treatment, improve surface adhesion, enhance adhesive and printing quality, etc. |
Ollital Technology would like to establish win-win business cooperation with distributors all over the world.
