Model Number:
Model Number:
OLT-5T 1Compliance:
CE CertifiedMixing method:
LCD displayVoltage:
Two Years Limited Warranty With Lifetime SupportWarranty:
Western Union, T/T, L/CPackaging Details:
Export wooden packageDelivery Time:
30dayOLLITAL ultrasonic extraction series is designed for applying a cavitation effect in a liquid by means of ultrasonic waves.It can be used to disintergrate cells of various kinds of animals and plants, viruses, bacteria, tissues as well as to reshape inorganic substances
It can also be used in emulsification, separation, distribution , collection cleaning and nano-material preparation ,dispersion acceleration of chemical reactions, etc. It has wide applications in teaching, researching, and manufacturing in many fields such as biology, microbiology, physics, zoology, agriculture and pharmacology and been used by some labs
|
Model No |
OLT-5T |
OLT-10T |
OLT-15T |
OLT-30T |
OLT-50T |
|
Working Frequency |
20-25KHz |
20-25KHz |
20-25KHz |
20-25KHz |
20-25KHz |
|
Ultrasonic power |
20-1000(W |
20-1200(W) |
200-1500(W) |
200-1800(W) |
250-2400(W) |
|
Reaction volume |
5L |
10L |
15L |
30L |
50L |
|
Tip Dia |
15 |
18 |
20 |
25 |
30 |
|
Working voltage |
220V |
220V |
220V |
220V |
220V |
|
Ultrasonic time |
0.1-99.9s |
0.1-99.9s |
0.1-99.9s |
0.1-99.9s |
0.1-99.9s |
|
Interval time |
0.1-99.9s |
0.1-99.9s |
0.1-99.9s |
0.1-99.9s |
0.1-99.9s |
|
Full time |
1-999min |
1-999min |
1-999min |
1-999min |
1-999min |
|
Power setting |
1-99% |
1-99% |
1-99% |
1-99% |
1-99% |
|
Duty Ratio |
0.1-99.9% |
0.1-99.9% |
0.1-99.9% |
0.1-99.9% |
0.1-99.9% |
|
Real measure Tem |
Yes |
Yes |
Yes |
Yes |
Yes |
|
Mixing power |
60W |
60W |
90W |
120W |
120W |
|
Stirring speed |
10-1200r/min |
10-1200r/min |
10-1200r/min |
10-1200r/min |
10-1200r/min |
|
Shelf |
Stainless |
Stainless |
Stainless |
Stainless |
Stainless |
|
Additives Volumetric flasks |
Yes |
Yes |
Yes |
Yes |
Yes |
|
Inlet/Outlet |
Yes/Yes |
Yes/Yes |
Yes/Yes |
Yes/Yes |
Yes/Yes |
|
Cooling capacity |
500W |
800W |
1200W |
2250W |
2250W |
|
Cooling temperature |
-5°C-room tem |
-5°C-room tem |
-5°C- room tem |
-5°C-roomtem |
-5°C- room tem |
Packing and Shipping
-The main parts will be wrapped with foam,then put into the carton; the mainbody portion will be packed in wooden cases;
-Both neutral and customized packaging can be available.
-We can ship the goods to you by International Express such as DHL,UPS,TNT,EMS and so on, you can also choose the appropriate one based on your timeline and budget. Besides,you can choose to use your own shipping agent
Ollital Technology would like to establish win-win business cooperation with distributors all over the world.
